Belling Machine SGK Series

Belling Machine » SGK Series

Pictures available of Belling Machine:

SGK Series

Belling Machine

Enquiry Now

Belling Machine Details

Features:
 High automation and high efficiency
 Stable quality and performance



Application:
 SGK series Belling Machine is especially used to bell PVC pipes, width range from 50mm to 630mm. It is an important device for PVC extrusion line. It has drawing device and program interface which is the same with extruding machine. It is also could separating operation.
 While expanding pipes, the pipe will be deliveried into the oven automatically for heating. The action is steady and correct. It does not damage pipe materials. The machine adopts double-infrared heating oven type. Each oven is equipped with heating core. The shaping method adopts expanding-end shaping.



Main parameter:

Model
SGK160
SGK200
SGK250
SGK315
SGK400
SGK500
SGK630
Pipe size (mm)
50-160
63-200
63-250
110-315
160-400
250-500
315-630
Qty of oven
1or2
1or2
1or2
1 or 2
1 or 2
1 or 2
1 or 2
Heating Power
8.4KW
10.5 KW
12 KW
18 KW
21 KW
21 KW
30 KW
Pipe Length
3-8m
3-8m
3-8m
3-8m
3-8m
3-8m
3-8m
Cooling Method
Water cooling or air cooling
Air Pressure
0.6Mpa
Water Pressure
0.4Mpa
Hydraulic Oil
46# wear resistance hydraulic oil





Belling Machine(Pipe Belling Machine) has been presented above, want more related products, please click the category below.
